Vibrating feeder -Customized Mining Equipment|Original Maker

Vibrating Feeder

The equipment relies on the exciting force generated by the vibration motor. The rotating eccentric blocks at both ends of the motor produce periodic inertial force, making the trough vibrate with high frequency and small amplitude. Under the combined action of inertial force and gravity, materials in the trough move continuously (by throwing or sliding) along the trough to achieve uniform and quantitative conveying. By adjusting the exciting force (via eccentric block angle), the feeding speed can be flexibly controlled to meet different process requirements. It features stable vibration, uniform feeding, and anti-clogging, widely used in mining, metallurgy, building materials and other industries to provide stable material supply for subsequent crushing and screening processes.

Performance advantage

1、Small Size, Light Weight, Compact Structure & Low Investment – The equipment features a streamlined design that cuts down on installation space and initial capital input while ensuring reliable performance.

2、Easy Installation, Minimal Maintenance and Low Operating Costs – The equipment is designed for convenient installation, requiring little maintenance work and resulting in low operating expenses.

3、Enhanced Material Fluidity Reduces Blockages, Enabling High Ore Discharge Capacity and Efficiency – Due to vibration, the fluidity of ore and rock materials increases, which reduces channel blockages, thus achieving large ore discharge capacity and high efficiency.

4、Continuous, Uniform and Controllable Vibrated Ore Flow with Adjustable Size and Safe Reliable Operation – The vibrated ore flow is continuous, uniform and easy to control; the ore flow size can be adjusted as needed, and the operation is safe and reliable.

5、Low Power Consumption and Significant Energy Saving – This series of vibrating feeders has low power consumption and achieves remarkable energy-saving effects.

6、Small Size, Light Weight, Simple and Compact Structure, Low Investment – The electrical control adopts half-wave rectifier electrical appliances, enabling stepless adjustment of feeding capacity. It can be used in automatically controlled production processes to realize automation of the production process while ensuring reliable performance.

7、No Rotating Components, Simple Structure and Easy Maintenance – It has no rotating parts, featuring a simple structure that facilitates convenient maintenance.

8、Trough Made of Alloy Steel Plate for Versatile Material Handling – The trough is made of alloy steel plate, which is suitable for conveying high-temperature, heavily worn and corrosive materials, etc.
